BGS-HLM25TC2
BGS-HLM25TC2
En stock
BGS, SUS housing, Class 2 laser, 50~250mm, NPN/PNP x 1, M8 4-pin connector
Sensor fotoeléctrico con tecnología BGS (Background Suppression), ideal para detección precisa a media distancia. Utiliza láser rojo Clase 2 visible, ofreciendo mayor precisión en aplicaciones exigentes. Construido con carcasa de acero inoxidable (SUS) para entornos agresivos. Cuenta con una salida NPN o PNP configurable y conexión mediante conector M8 de 4 pines.
Características Técnicas
-
Tipo de sensor: Supresión de fondo (BGS)
-
Material del cuerpo: Acero inoxidable (SUS)
-
Fuente de luz: Láser rojo visible, Clase 2 (IEC 60825-1)
-
Distancia de detección: 50 a 250 mm (ajustable)
-
Salida: 1 salida NPN o PNP (configurable por cableado)
-
Tensión de alimentación: 10 ~ 30 VDC
-
Corriente máxima de salida: 100 mA (colector abierto)
-
Frecuencia de respuesta: ≥ 1 kHz
-
Conector: M8, 4 pines
-
Pin 1: V+
-
Pin 2: 0V
-
Pin 3: Salida NPN/PNP
-
Pin 4: No conectado (o función especial según modelo)
-
-
Modo de operación: Light ON / Dark ON (seleccionable)
-
Protecciones:
-
Contra inversión de polaridad
-
Contra cortocircuito
-
Contra sobrecarga
-
Condiciones Ambientales
-
Grado de protección: IP67
-
Temperatura de funcionamiento: -25 °C a +55 °C
-
Resistencia a vibraciones: Alta (según normas IEC)
-
Montaje: Rosca M18 o soporte opcional
-
Indicadores LED: Estado de alimentación y salida
Aplicaciones Típicas
-
Líneas de producción automatizadas
-
Control de objetos reflectantes y no reflectantes
-
Industria de alimentos, farmacéutica, automotriz, metalmecánica
-
Ambientes con humedad, polvo o sustancias químicas
Certificaciones
-
CE
-
RoHS
-
Láser Clase 2 (IEC 60825-1)
-
Alta inmunidad a interferencias (EMC)
